AIRTAC

TR16X Twin-rod Cylinder

Regular price €68,09 EUR
Regular price Sale price €68,09 EUR
Sale Sold out
Shipping calculated at checkout.
TR16X Twin-rod Cylinder

AIRTAC CYLINDERS - TR series dual shaft cylinder

PDF

TWIN ROD CYLINDER

Airtac TR cylinders are a functional replacement for the SMC CXS series cylinders

--Fluid : Air

-- Acting type : Double Acting

  1. JIS standard is implemented.
  2. The non-rotating precision is high and deflection of the end of piston rod is low, which is suitable for precise guide.
  3. It adopts lengthening type sliding supporting guide. No additional lubricant is needed and it has good performance of guide.
  4. Mounting holes on three sides facilitates multi-position mounting.
  5. It is good resistance to bending and twisting moments.
  6. Except for the axial, each side of the cylinder has installation orifices to provide several installation and fixation ways for the customers
  7. There are two groups of air intake and outlet at two sides of the cylinder for the actual selection.
  8. Bumper in front of the barrel can adjust the stroke of cylinder and relieve impact.
  9. Standard configuration of this series has magnet and the type without magnet is not available.

VARIANTS OF THE CODE AVAILABLE :



TR16X100S   TR16X10S   TR16X120S   TR16X125S   TR16X150S   TR16X15S

TR16X175S   TR16X200S    TR16X20S   TR16X15S    TR16X30S    TR16X35S

TR16X40S    TR16X45S    TR16X50S    TR16X50SH    TR16X55S     TR16X5S

TR16X60S   TR16X60SH    TR16X65S     TR16X70S    TR16X75S     TR16X80S

TR16X85S   TR16X85S
